کانکتور روسی نری فلنج کامل 20 پین قطر 48 میلی متر

Cylindrical low-frequency non-sealed connector is designed for operation in electrical circuits of direct and alternating currents with a frequency of up to 3 MHz at a voltage of up to 850 V.

Main technical characteristics :

– Contact resistance ….. not more than 1.3 mΩ

– Insulation resistance ….. not less than 5000 MΩ

– Maximum current load per single contact ….. 35 A

– Number of joints-dismemberments ….. 500

– Operating temperature range ….. from -60 to +70°С

– Minimum operating time ….. 1000 hours

– Shelf life ….. 25 years
