: current load
for a single contact – 10 A
maximum total per contactor – 83 A
The maximum operating voltage is 560 V
The diameter of the socket contacts is 1.5 mm
Contact resistance – no more than 2.5 MOhm
The capacitance between contacts – no more than 6 pF
Insulation resistance – not less than 5000 MΩ
Minimum operating time – 1000 hours
The number of articulations-dismemberments – 500
Gamma-percentage shelf life – 15 years
The tightness of the connector is leaky
Product length connector – 62.5 mm
Weight – no more than 27 g
|
 |
 |
The diameter of the mounting hole of the connector is 24 mm
The diameter of the contacts is 1 mm
to withstand the maximum operating voltage up to 560 V
The current load is up to 50 A
Number of contacts – 10
|
